关键参数速览
- 电源电压 VCC
- 36
产品特点 Features
- Wide Supply Ranges • Low Input Bias Current: 25 nA (Typ)
- Single Supply: 2 V to 36 V • Low Input Offset Current: 3 nA (Typ) (LM139)
- (Tested to 30 V for Non-V Devices and 32 V • Low Input Offset Voltage: 2 mV (Typ) for V-Suffix Devices)
- Common-Mode Input Voltage Range Includes
- Dual Supplies: ±1 V to ±18 V
- Ground
- (Tested to ±15 V for Non-V Devices and
- Differential Input Voltage Range Equal to
- ±16 V for V-Suffix Devices)
- Maximum-Rated Supply Voltage: ±36 V
- Low Supply-Current Drain Independent of
- Low Output Saturation Voltage
- Supply Voltage: 0.8 mA (Typ)
- Output Compatible With TTL, MOS, and CMOS
- LM139, LM139A. . . D, J, ORW PACKAGE LM139, LM139A. . . FK PACKAGE
- LM239. . . D, N, OR PW PACKAGE (TOPVIEW)
绝对最大额定值 Absolute Maximum Ratings（TA = 25°C）
超过下表数值可能造成器件永久损坏，设计时请留余量。
| 最小 | 最大 | 单位 |
|---|---|---|
| V Supply voltage(2) | 36 | V |
| V Differential input voltage(3) | ±36 | V |
| V Input voltage range (either input) –0.3 | 36 | V |
| V Output voltage | 36 | V |
| I Output current D package DB package | 20 86 96 | mA |
| θ Package thermal impedance, junction to free air(5) (6) N package NS package | 80 76 | °C/W |
| PW package | 113 | |
| FK package | 5.61 | |
| W package | 14.65 | |
| T Operating virtual-junction temperature | 150 | °C |
| Case temperature for 60 s FK package | 260 | °C |
| Lead temperature 1,6 mm (1/16 in) from case for 60 s J package | 300 | °C |
| T Storage temperature range –65 | 150 | °C |
| (2) All voltage values, except differential voltages, are with respect to network ground. | ||
| (3) Differential voltages are at IN+ with respect to IN–. | ||
| Product Folder Links: LM139 LM239 LM339 LM139A LM239A LM339A LM2901 LM2901AV LM2901V |
数据来源：原厂规格书
电气特性 Electrical Characteristics（TA = 25°C）
| 最小 | 典型 | 最大 | 最小2 | 典型2 | 最大2 |
|---|---|---|---|---|---|
| LM139 LM239 | LM139A LM239A |
