产品实拍图
本页为博科信现货实拍（器件丝印 见规格书）。图片已加防盗水印，需要最新批次照片或未加水印原图请联系销售；点击图片可放大。
关键参数速览
- 正向电压 VF
- 1.3
- 正向电流 IF
- 1.3
- 集电极-发射极电压 VCEO
- 80 V
- 工作温度 TA
- −0.5 (Ta ≥ 25°C) mA /°C
绝对最大额定值 Absolute Maximum Ratings（TA = 25°C）
超过下表数值可能造成器件永久损坏，设计时请留余量。
| Characteristic | 符号 | 单位 |
|---|---|---|
| TLP280 | TLP280−4 | |
| Forward current | IF(RMS) | ±50 mA |
| Forward current derating | ΔIF /°C −0.7 (Ta ≥ 53°C) | −0.5 (Ta ≥ 25°C) mA /°C |
| Pulse forward current | IFP ±1 (100μs | pulse, 100pps) A |
| Junction temperature | Tj | 125 °C |
| Collector−emitter voltage | VCEO | 80 V |
| Emitter−collector voltage | VECO | 7 V |
| Collector current (1 circuit) | IC PC 150 | 50 mA 100 mW |
| ΔPC /°C −1.5 | −1.0 mW /°C | |
| derating (Ta ≥ 25°C) (1 circuit) | ||
| Junction temperature | Tj | 125 °C |
| Storage temperature range | Tstg | −55~125 °C |
| Operating temperature range | Topr | −55~100 °C |
| Lead soldering temperature (1 circuit) | Tsol 260 PT 200 | (10s) °C 170 mW |
| ΔPT /°C −2.0 | −1.7 mW /°C | |
| derating (Ta ≥ 25°C) (1 circuit) |
数据来源：原厂规格书
安全与绝缘额定值（DIN EN/IEC 60747−5−5）
| Characteristic | 符号 | 单位 |
|---|---|---|
| TLP280,TLP280−4 | ||
| report and estimated | failure rate, etc). 3 | 2007-10-01 |
电气特性 Electrical Characteristics（TA = 25°C）
| Characteristic | 符号 | 测试条件 | 最小 | 典型 | 最大 | 单位 |
|---|---|---|---|---|---|---|
| Forward voltage | VF IF | = ±10 mA | 1.0 | 1.15 | 1.3 | V |
| Capacitance | CT V | = 0, f = 1 MHz | ― | 60 | — | pF |
| breakdown voltage | V(BR) CEO IC | = 0.5 mA | 80 | ― | — | V |
| breakdown voltage | V(BR) ECO IE | = 0.1 mA | 7 | ― | — | V |
| Ambient light below | ― | (2) 2 | (10) 50 | μA | ||
| Ambient light below | ― | (4) | (50) | μA | ||
| CCE V | = 0, f = 1 MHz | ― | 10 | ― | pF | |
| 50 | — | 600 | ||||
| TLP280,TLP280−4 |
