Name: TOSHIBA TLP290(GR-TP,SE(T
Brand: TOSHIBA
Availability: InStock

产品实拍图

本型号暂无已核对的专属实拍图。为避免图文不符，本页不放同系列近似图；如需实物照片，请联系销售获取本批次实拍。

关键参数速览

超过下表数值可能造成器件永久损坏，设计时请留余量。

Characteristic	符号	备注	额定值	单位
R.M.S. forward current	IF(RMS)		±50	mA
Input forward current derating (Ta ≥ 90°C)	∆IF /∆Ta		-1.5	mA /°C
Input forward current (pulsed)	IFP	(Note 2)	±1	A
Input power dissipation	PD		100	mW
Input power dissipation derating (Ta ≥	90°C) ∆PD/∆Ta		-3.0	mW/°C
Junction temperature	Tj		125	°C
Collector-emitter voltage	VCEO		80	V
Emitter-collector voltage	VECO		7	V
Collector current	IC		50	mA
Collector power dissipation	PC		150	mW
Collector power dissipation derating (Ta ≥	25°C) ∆PC /∆Ta		-1.5	mW /°C
Junction temperature	Tj		125	°C
Operating temperature range	Topr		-55 to 110	°C
Storage temperature range	Tstg		-55 to 125	°C
Lead soldering temperature	Tsol		260 (10s)	°C
Total package power dissipation	PT		200	mW
Total package power dissipation derating (Ta	≥ 25°C) ∆PT /∆Ta		-2.0	mW /°C

数据来源：原厂规格书

Characteristic	符号	测试条件	最小	典型	最大	单位
DEL Input forward voltage	VF I F	= ±10 mA	1.1	1.25	1.4	V
Input capacitance	CT V	= 0 V, f = 1 MHz	-	60	-	pF
Collector-emitter breakdown	voltage V(BR) CEO IC	= 0.5 mA	80	-	-	V
rotceteD Emitter-collector breakdown	voltage V(BR) ECO IE	= 0.1 mA	7	-	-	V
		VCE = 48 V,	-	0.01	0.08	μA
		VCE = 48 V, Ta = 85°C	-	2	50	μA
Collector-emitter capacitance	CCE V	= 0 V, f = 1 MHz	-	10	-	pF
			50	-	600 TLP290(SE

TLP290(SE

图纸取自该型号原厂规格书的应用电路与封装尺寸章节，点击图片可放大查看原始尺寸标注。
