产品应用与封装尺寸
图纸取自原厂规格书，点击可放大查看原始尺寸标注。
引脚定义与内部结构
| 引脚 | 符号 | 名称 |
|---|---|---|
| 1 | SON | |
| 2 | GND | |
| 3 | QFN | |
| 4 | GND | |
| 7 | V |
数据来源：原厂规格书引脚图
关键参数速览
- 正向电压 VF
- 0.95
- 正向电流 IF
- –25
- 电源电压 VCC
- 5.5
- 工作温度 TA
- V CC + 25
产品特点 Features
- TPD2E001
绝对最大额定值 Absolute Maximum Ratings（TA = 25°C）
超过下表数值可能造成器件永久损坏，设计时请留余量。
| 最小 | 最大 | 单位 |
|---|---|---|
| V –0.3 | 7 | V |
| V –0.3 | V + 0.3 | V |
| T Storage temperature range –65 | 150 | C |
| T Junction temperature | 150 | C |
| Infrared (15 s) | 220 | |
| Bump temperature (soldering) | C | |
| Vapor phase (60 s) | 215 | |
| Lead temperature (soldering, 10 s) | 300 | C |
数据来源：原厂规格书
电气特性 Electrical Characteristics（TA = 25°C）
| 参数 | 测试条件 | 最小 | TYP(1) | 最大 | 单位 |
|---|---|---|---|---|---|
| V Supply voltage | 0.9 | 5.5 | V | ||
| I Supply current | 1 | 100 | nA | ||
| V Diode forward voltage I | = 10 mA | 0.65 | 0.95 | V | |
| V Breakdown Voltage I | = 10mA | 11 | V | ||
| T | A = 25 C, – 15-kV HBM, Positive | transients | V CC + 25 | ||
| I | F = 10 A Negative | transients | –25 | ||
| T | = 25 C, Positive | transients | V + 60 | ||
| V Channel clamp voltage(2) – | 8-kV Contact Discharge | V | |||
| C | Negative | transients | –60 | ||
| T | = 25 C, Positive | transients | V | + 100 | |
| Negative | transients | –100 | |||
| I Channel leakage current V | = GND to V | – 1 | nA | ||
| C Channel input capacitance V | = 5 V, Bias of V /2 | 1.5 | pF |
